nLTS-PE

SimulCharge™, PoE, Ethernet Adapter for Lenovo Micro USB Tablets

$119.99 / Web Price

The nLTS-PE provides compatible Lenovo Micro-USB tablets with Power over Ethernet (PoE) and Ethernet, while also keeping it charged. It also features Docking Detect technology.

The adapter provides 10.4 watts up of charging power and a reliable 10/100-capable network connection through a single CAT5/5e/6 Ethernet cable connected to a PoE-enabled switch. PoE provides power and data through the same Ethernet cable. This allows you to place the adapter up to 328 ft (100 m) from the power source. It can be installed in locations with no easily accessible AC outlets or in environments where extension cords or dedicated AC lines are prohibited, inconvenient or expensive.


PRODUCT DESCRIPTION

The LAVA nLTS-PE adapter provides compatible Lenovo Micro USB tablets with simultaneous charging and access to data. It features Power over Ethernet (PoE), Ethernet and Docking Detect technology.

Leveraging PoE technology, the enclosure does not require a dedicated AC source, as it can be fully powered through its built-in Ethernet port*. Simultaneously, this port can provide 10/100 Ethernet connectivity between the tablet and network, providing a single cable solution for tablet power and data. PoE allows greater options for tablet placement as it can be used in areas with limited electrical outlets. It can be placed up to 328 ft (100 m) from the power source.

Docking Detect ensures the “greeting” protocols between the SimulCharge adapter and mobile device are executed correctly and consistently every time they are connected. This allows the adapter to be a plug-and-play technology that ensures the mobile device always operates in USB Host mode.

The SimulCharge™ adapter comes with a casing and a Micro USB to Micro USB cable to connect the tablet.

The nLTS-vc2UE is not compatible with all Lenovo tablets.
Please see the list of tested Lenovo devices.

nLTS_PE_PortClarification_A01nLTS_PE_PortClarification_Board_A01

*The tablet can also be powered through the adapter’s Micro USB-B port, which is rated for the standard 5 volts at 2 amps. It is recommended to use the charging cable that came with the tablet.

ADDITONAL INFORMATION




System Requirements


Specifications

CABLES
1 x Micro USB to Micro USB cable (3.3 ft / 1 m) to the tablet.
Note: The cable is included with the adapter.
PORTS/CONNECTORS
1 x RJ45 10/100 Ethernet port (LAN)
1 x Micro USB port (for tablet connection)
1 x Micro USB-B port (the Aux. 5V input)
1 x Charge status LED
1 x Device Link LED
1 x Ethernet Link/Activity LED
1 x Tablet USB Activity LED
POWER INPUT
RJ-45 PoE connector (Ethernet LAN and power).
The Aux. 5V Input optional for a testing purpose (no PoE is applied)
MEASUREMENTS
Depth: 4.96 inches (126 mm)
Width: 3.8 inches (97 mm)
Height: 1.69 inches (42 mm)
Weight: 4.3 oz

Features


Applications

POINT OF SALES
Product Catalogues
Price Checking
Line Busting & Ticketing
POS systems
Menus, order taking
Transportation & Logistics endpoints
Digital Signage
WORKFORCE MANAGEMENT
Conference Room Scheduling
Timecard
Dispatching
In-vehicle data capture
Virtual Concierge
Patient Check In
KNOWLEDGE SHARING
Web/Video conferencing
Trade Show Guides
Customer Surveys
Remote control
Way-finding
QUALITY CONTROL
Material tracking
Production
Scheduling
