SimulCharge™ 3 x USB Hub with Battery Modulation for Samsung Tablets
$69.99 / VC Option $84.99
The eSTS-3U adapter is an extended version of STS-3U that features 3 ports USB hub for peripherals, tablet operation as a USB Host while being charged (SimulCharge), the RBM technology for the battery modulation, and screen brightness management for the Samsung tablets. This adapter includes three USB 2.0 (Type-A) ports for connecting three additional USB peripherals. The eSTS-3U uses a standard USB power supply provided with the tablet.
Available with an optional built-in voltage converter. Allows an external 9 V up to 36 V DC power supply to be placed up to 50 feet away from the tablet.
Sales Contact: firstname.lastname@example.org
Have a Question? Call: 1-800-241-5282 (US & Canada) or 1-416-674-5942
- Designed for selected Samsung Tablets
- USB Host operation while charging
- Battery Modulation for tablet longevity
- Screen Brightness control for reduced heat generation
- Support for installations running 24/7
- 3 x USB-A (USB 2.0) ports
- Uses an original power brick
- Maintenance resets of tablet and module hardware
- Permission for all integrated USB devices handled by Samsung KNOX
- eSTS Mode, Charge State & a HUB Status indicator lights
- No tablet rooting required
- LAVA Limited Warranty
SimulCharge™ - the technology that enables possibilities
RBM - the extension that makes them last
USB HOST OPERATION WITH SIMULTANEOUS TABLET CHARGING (SIMULCHARGE)
The eSTS-3U operates in SimulCharge mode. This technology allows the charging of the selected Samsung tablets while interacting with USB accessories. Standard USB OTG Adapters do not allow the tablet to be charged while operating with USB peripherals.
The battery modulation allows the tablet to be repetitively charged up to an upper battery level and then allowed to discharge to a lower battery level. This mimics the standard charge cycles of charging a tablet and then disconnecting the charger before it will start a trickle charging (overcharging).
The BM technology improves battery tablet longevity.
SCREEN BRIGHTNESS MANAGEMENT
The LAVA Tablet Manager lets you control the brightness of the tablet based on a time of the day. This reduces the tablet heat generation, power consumption, and optimizes the brightness for the commercial use.
The STS-PE can be used on its own, or as part of a third-party enclosure solution, supporting a variety of kiosk-type applications.
TO A SWOLLEN
Enjoy the convenience of
safe tablet charging 24/7 for your tablet kiosk.
|Tablet:||See the tested devices list|
|Power Supply:||USB Charger/Power Supply with a Micro USB-B connector, such as the power supply provided with the Galaxy tablet. Any regulated 5 volt power supply capable of at least 2 amperes can be used.
Optional built-in voltage converter allows an external 9 V to 36 V DC power supply to be placed up to 50 feet away from the tablet.
|Measurements:||Depth: 3.3 inches (83 mm)
Width: 3.8 inches (97 mm)
Height: 1.7 inches (44 mm) – with standoffs
Weight: 7.0 oz (shipping)
Weight: 4.1 oz (device only)
POINT OF SALES
- Product Catalogues
- Price Checking
- Line Busting & Ticketing
- POS systems
- Menus, order taking
- Transportation & Logistics endpoints
- Digital Signage
- Conference RoomScheduling
- In-vehicle data capture
- Virtual Concierge
- Patient Check In
- Web/Video conferencing
- Trade Show Guides
- Customer Surveys
- Remote control
- Material tracking
1 x Micro USB B to Micro USB B cable (3.3ft/1m)
Note: The custom 3.3ft/1m cable connects the device to the tablet. This cable may not be extended.
3 x USB A port (for USB 2.0 accessories)
1 x Micro USB B port (for Tablet connection)
1 x Micro USB B port (the 5V power input)
1 x eSTS Mode indicator LED
1 x Charge State indicator LED
1 x USB Hub Status indicator LED
VC Option: 1 x Barrel (2.0 mm) DC Output Connector (Centre Pin Positive)
Hundreds of hours of testing, many months of design work, in-depth field trials, and close collaboration with Samsung has gone into developing LAVA SimulCharge solutions for Galaxy tablets. Designed for lifetime performance, each LAVA device is individually tested and covered by the LAVA’s industry-leading warranty.
